Relays
Magnetic latching relays (SH31A / SH31E series) with low power consumption and high switching capability.
Telecom, Automotive, Reed Relays
Features
- Dual coil available
- Low power consumption
- Switch capability up to 120A
- Short-circuit current capability up to 6000A
- RoHS compliant
Technical Specifications
| Contact material | Silver alloy |
| Max switching current | 60A / 90A / 120A |
| Max switching voltage | 250VAC |
| Dielectric strength | 4000VAC (1 min) |
| Ambient temperature | -40°C to +70°C |
